Brady EXA81 RFID Reader EU
Part Number: B-EXA81-EU
Description
- Best mobile RFID reading capabilities: read 1000+ items per second within 15 metres
- Scan anything: read UHF RFID labels from up to 15 metres, and easily scan barcodes, and 2D codes up close.
- No battery swaps: works 24 hours on a single charge
- Great connectivity: compatible with a wide range of smart devices that can be linked wirelessly via Bluetooth 5.3 or with USB-C cable
- Universal mounting: firmly attach any smart device using screws or Quadlock
- Scan quickly: ergonomic pistol grip with trigger enables fast and easy scanning all day long
Key Features
- Ingress Protection Rating: IP65
- Application(s): Asset tracking, Facility identification, Food and Beverage Process labelling, General identification, Inspection tagging, RFID labelling, Security identification, Temperature indicating labelling, Warehouse marking
- Connectivity Options: Bluetooth® 5.3 class 2, USB-C
Specifications
Key Characteristics
| Article Number | 321710 |
|---|---|
| Order Reference | B-EXA81-EU |
| Total Qty per Pack | 1 Piece(s) / Box |
| Minimum Order Quanitity | 1 |
| RF Radiated Power | Max. ERP 2 W (33dBm) / EIRP 3.3 W (35.2dBm) |
| Application(s) The type of application or end use environment the product is designed for. | Asset tracking, Facility identification, Food and Beverage Process labelling, General identification, Inspection tagging, RFID labelling, Security identification, Temperature indicating labelling, Warehouse marking |
| Quantity | 1 |
| Brand | Brady® |
| Country of Origin Identifies where a product is manufactured or produced. It can determine tariffs and trade rules. | Finland |
Dimensions
| Reading Speed | Up to 1000 tags per second |
|---|---|
| Size - Width (mm) | 214.4 mm |
| Size - Height (mm) | 98.5 mm |
| Size - Depth (mm) | 86 mm |
| Weight (kg) | 0.580 kg |
| Dimensions | 214.4 mm (W) x 98.5 mm (H) x 86 mm (D) |
| Beam Width | 80° |
Material Characteristics
| Colour | Blue, Black |
|---|
Product Features
| Battery mAh Rating | 10050 mAh |
|---|---|
| Maximum Receive Sensitivity | -85dBm |
| Antenna Features | Gain 5 dBi with software-controlled polarisation switching |
| Battery Type | Rechargeable Lithium-ion Battery |
| Battery Weight (metric) | 80.000 |
| Connectivity Options The way in which the printer or scanner can be connected to an external device, PC or Application. | Bluetooth® 5.3 class 2, USB-C |
| How Is Battery Shipped | Shipped installed in equipment |
| Interface Type | Buttons |
| RFID capabilities | UHF |
| Barcode Symbologies | Code 11, Code 39, Code 93, Code 128, GS1-128, GS1 DataBar, Interleaved 2 of 5, Codabar (NW-7), MSI, MSI, Telepen, China Post, POSTNET, EAN/UPC, EAN-13, EAN-8, Industrial 2 of 5, EAN-13, Industrial 2 of 5, Aztec, Data Matrix, GS1 DataMatrix, MaxiCode, PDF417, MicroPDF417, QR code, Aztec, Chinese Sensible Code, Composite Code, Passport MRZ |
| Mounting Type | Quad Lock, Screws |
| Operating Humidity Range | 10%-95% (non-condensing) |
| Operating System | Nordic ID technology IoT platform by Brady |
| Operating Temperature | -20°C - 55°C |
| Power Source | Rechargeable Battery |
| Power Supply Voltage | 100 - 240 V @ 50 - 60 Hz |
| Decode Capabilities - 1D | IATA 2 of 5, Matrix 2 of 5, Trioptic |
| Shipped With Battery | Yes |
| Storage Temperature | -20°C - 60°C |
| Style | Pistol grip |
| ISO Conformance Standards | ISO 18000-63 (EPC Class 1Gen2v2 - RAIN) |
| Decode Capability - 1D Stacked | Codablock F |
| Decode Capability - 2D | Aztec Code |
| Decode Capability - Postal | Itelligent Mail |
| Scanner Model | Nordic ID technology by Brady NUR3-1W engine |
| ESD | Air discharge: +/-8kVdc, Contacts: +/-4kVdc |
| Charging Times | Charging over cradle (0 - 100 %) 4 h, Charging over USB-C connector (0 - 100 %) 4–10 h |
Printing Specifications
| Device Indicators | Buzzer for sound indications, Connection LED, Power LED, Scan LED, Segmented LED bars |
|---|---|
| Drop Test | Resistant to 1.8 metre drops |
What's Included
| Includes | This product is delivered with EXA81 device, safety and regulation guide and a wrist wrap. |
|---|---|
| Warranty | 2 years |
Compliance
| UNSPSC Standardises product/service classification globally. | 43211701 |
|---|---|
| RoHS Compliance Status | Compliant with 2011/65/EU with exemptions |
| REACH SVHC Status | Part contains an SVHC |
| REACH Candidate List Date | 14 June 2023 |
| Approval/Compliance | CE |
| Printer can be shipped to | Albania, Andorra, Armenia, Austria, Belarus, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Finland, Germany, Greece, Hungary, Iceland, Italy, Kosovo, Latvia, Liechtenstein, Lithuania, Luxembourg, Malta, Metropolitan France, Moldova, Monaco, Montenegro, Netherlands, Norway, Poland, Portugal, Romania, San Marino, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey, Ukraine (Excluding Crimea Region), United Kingdom |
| Safe Use Instructions | SUI_RFID_Devices.pdf |
| Ingress Protection Rating Rating of protection provided against intrusion, dust, accidental contact, and water by mechanical casings and electrical enclosures. | IP65 |
Guides and Videos
Product Overviews & Specs
- Every asset a unique digital identity - Complete RFID Solutions brochure (EUR-M-322-EN) [PDF]
- RFID Succes Stories (presentation in pdf format) [PDF]
-
EXA81 RFID Reader - introduction video
Customers also bought
-
Quad lock Universal Adaptor for EXA31 and EXA81
EXA81-QUADLOCK
£27.00 -
Quickcharge 3 Adapter USB-C kit EU/UK/US
ADPT-QC3-USB-KIT
£44.52 -
Brady IRX200 Rugged Profinet RFID Fixed Reader EU
B-IRX200-EU
£1,340.91 -
Brady FR22 Fixed RFID Reader LTE EU with GA30 antenna
B-FR22LTE-GA30-EU
£2,187.72 -
Brady FR22 Fixed RFID Reader EU with GA30 Antenna
B-FR22-RDR-GA30-EU
£2,009.23 -
Brady XA20 UHF RFID Antenna EU
B-XA20-ANT-EU
£220.49 -
HH85 Handheld RFID Reader LTE with Pistol Grip - UHF, NFC, Barcode
B-HH85-UHF-LTE-EU
-
FR22 Fixed RFID Reader LTE
B-FR22-RDR-LTE-EU
£1,916.10 -
BFA868 RFID Antenna for FR22 Fixed RFID Reader
B-BFA-ANT-868
£1,258.88 -
BFA915 RFID Antenna for FR22 Fixed RFID Reader
B-BFA-ANT-915
£1,258.88
A personal radar for your phone
Put every asset, tool and item your team needs to service, use or pick on their radar. Literally. The EXA81 smartphone and tablet add-on turns mobile devices into personal radars. It enables every team member to quickly find any item labelled with battery-free RFID labels, without needing line of sight.
Find without searching
Easily read up to 1000 RFID-labelled items per second within 15 metres, with a single scan. Select the item you need on your smartphone or tablet screen, and quickly home in with sounds and visuals. Line of sight is not required, and you will not need to find, move, flip or rotate items and assets to scan a barcode.
Your phone. Your apps.
Easily empower your Android and Apple phones and tablets with the EXA81 to add an RFID read range of up to 15 metres. Firmly attach mobile devices with screws or Quadlock and link your phone or tablet via Bluetooth 5.3 or USB-C. Your device now has an ergonomic pistol grip to trigger scans of UHF RFID labels, barcodes, 2D codes and NFC labels for up to 24 hours on a single charge.
In addition, we can provide an app to get you going, develop a custom application tailored to your business needs, or adapt an existing company app to present incoming data in any way you want.
Full inventories on your phone
And that is not all. Quickly check centralised inventory data with actual inventories by comparing incoming data from items and assets identified with battery-free RFID labels. Just walk through while scanning to cover the entire space, or get support from fixed RFID reader systems. Home in on excess inventory and highlight missing items, or forward actual inventories for comparison at a later time.
Brady RFID Demo App
Combine your RFID reader with the RFID Demo App to explore various straightforward RFID functionalities such as performing inventory management and writing, authenticating and locating RFID labels/tags.
Download
