Dimensions:

42.00 mm (W) x 85.00 mm (H)
Application Area:

Off-metal (carton, wood, plastic, glass, etc.)
Brady Material Type:

Polyester
Finish:

Gloss
Brady Material No.:

L-2588-32A (View Technical Data Sheet)
Colour:

White
Read Range (metric):

Up to 2.7 metres
Printer Compatibility:

Sato CL4NX Plus
Application(s):

General identification, Inventory and inspection labelling, RFID labelling, Water Indicating labelling

Moisture Sensing RFID Labels Add To Compare In Compare

Order Reference:

THT-UHF-B423-42X85

Contact Customer Service

Overview

UHF moisture label is a general-purpose moisture sensor that is designed to detect and measure moisture levels in the surrounding environment, and it works across a wide variety of materials, providing both good read distance and sensing performance. This label is suitable for use in outdoor, indoor and UV exposed environments.

UHF moisture label for general applications such as construction, healthcare, retail, industry, supply chain and others. The antenna is designed for application on non-metal surfaces.
Polyester tag face material, with chip bonded to aluminium antenna using anisotropic conductive film adhesive, suitable for thermal transfer printing, including RFID encoding.
Labels are outside wound and 100% inspected, 500 good RFID labels per roll with bad tags marked.

A complete RFID solution

Give every asset a unique, digital identity with reliable RFID labels. Track, manage and monitor assets, items and products more efficiently our complete RFID solutions, including labels, readers, app development, software integration and installation.

Find out more

Customise your solution

Contact our specialists to help you select the right identification solution for your items, your environment and your application. For specific applications, our engineers can modify the construction of your RFID label to maximise its benefits for your organisation.

Find out more

Specifications

Key Characteristics


Key Characteristics	Article Number	311513
	Order Reference	THT-UHF-B423-42x85
	Total Qty per Pack	100 Label(s) / Roll
	Minimum Order Quanitity	1
	QTY. per Row	1
	Application(s)	General identification, Inventory and inspection labelling, RFID labelling, Water Indicating labelling
	Quantity	100
	Brand	Brady®
	Qty per Roll	100
	Ribbon Series	R6000HF
	Country of Origin	BE

Dimensions


Dimensions	Size - Width (mm)	42.00 mm
	Size - Height (mm)	85.00 mm
	Antenna Length (metric)	80.70 mm
	Antenna Width (metric)	38.00 mm
	Weight (kg)	0.00082 kg
	Vertical Repeat (mm)	96.04 mm
	Web Width (mm)	47.00 mm
	Dimensions	42.00 mm (W) x 85.00 mm (H)

Material Characteristics


Material Characteristics	Brady Material No.	L-2588-32A (View Technical Data Sheet)
	Brady Material Type	Polyester
	Material Properties	RFID-enabled
	Thickness (mm)	0.300 mm
	Colour	White
	Application Area	Off-metal (carton, wood, plastic, glass, etc.)
	Max. Service Temp. °C	120 °C
	Min. Service Temp. °C	-80 °C
	Adhesive	Permanent Acrylic
	Finish	Gloss

Product Features


Product Features	Integrated Circuit Chip	EM EM4152V001WS6U
	Operating Frequency	Global (860 – 960 MHz) (ETSI band)
	EPC Memory	96 bits
	Read Range (metric)	Up to 2.7 metres
	TID (locked) Memory	96 bits
	Frequency Type	UHF
	Operating Temperature	-40°C - 85°C
	Supported Standards (Application)	EPC Class 1 Gen2v2 – ISO 18000-63

Printing Specifications


Printing Specifications	Print Technology	Thermal Transfer

Compatibility


Compatibility	Printer Compatibility	Sato CL4NX Plus

Compliance


Compliance	UNSPSC	55121612
	RoHS Compliance Status	Compliant with Directive 2011/65/EU and 2015/863
	REACH SVHC Status	Part does not contain an SVHC
	REACH Candidate List Date	17 January 2022

Support

Videos

RFID Moisture Sensing Labels Introduction Video

RFID or barcode for asset tracking: How to make the right choice for your business? - Video

GIVE EVERY ASSET A UNIQUE DIGITAL ID - Overview video

Literature

Technical data sheet for RFID label L-2588-32A

RFID Succes Stories (presentation in pdf format)
